Andrea Persici

Context. Galactic cosmic rays (GCRs) and solar energetic particles (SEPs) with energies greater than tens of megaelectron volts are at the origin of spacecraft deep charging. The High Energy Telescope of the Energetic Particle Detector instrument measures the particle flux incident on the Solar Orbiter spacecraft. An algorithm implemented in the processing electronics of the visible light (VL) instrument of the Metis coronagraph generates cosmic-ray matrices containing the pixels fired by high-energy particles. These independent observations allow us to monitor the secondary particle production into the spacecraft. Aims. We studied the GCR flux long-term variations during the ascending phase of solar cycle 25 and the evolution of two SEP events observed on July 24–26, 2023, and on February 9–14, 2024, above 80 MeV with the aim of evaluating the impact of galactic and solar high-energy particles on Metis. Methods. A Python tool named REBECCA has been developed for the automated analysis of the Metis cosmic-ray matrices. The number of observed particle tracks is compared to Monte Carlo simulations of the Metis VL bidimensional CMOS sensor used as a particle detector. Results. We present the modulation of the GCR energy spectrum from 2020 through 2024 above 100 MeV. The dynamics of two intense SEP events is also reported. Monte Carlo simulations indicate that the composition of particles in the cosmic-ray matrices is dominated by protons. Going from solar minimum to maximum, an increase in particles produced by cosmic rays in the spacecraft material surrounding Metis was observed. Conversely, during the whole evolution of SEP events, protons made up more than 90% of the particles. These observations were gathered near the ecliptic during a positive polarity epoch of the global solar magnetic field. Analogous studies will be conducted during the negative polarity epoch, within 1 au, both above and below the ecliptic plane, throughout the remaining duration of the mission.

Context. The Solar Orbiter Metis coronagraph captures images of the solar corona in both visible (VL) and ultraviolet (UV) light. Tracks ascribable to the passage of galactic and solar particles appear in the Metis images. An algorithm implemented in the Metis processing electronics allows us to separate the pixels fired by VL photons from those crossed by high-energy particles. These spurious pixels are stored in cosmic-ray matrices that can be visually analyzed for particle monitoring deep into the spacecraft’s interior. This algorithm has been enabled for the VL instrument only, since the process of separating the particle tracks from pixels fired by photons in the UV images was shown to be quite challenging with respect to a quantitative analysis. Aims. This work is aimed at studying galactic cosmic rays (GCRs) and solar energetic particles (SEPs) with the Metis cosmic-ray matrices in February 2023. Methods. We compared a visual analysis of Metis cosmic-ray matrices gathered on February 22, 2023, with GCRs only, and on February 25, 2023 with both GCRs and SEPs, to Monte Carlo simulations of the VL instrument during the same days. Results. We estimated the solar modulation parameter associated with the GCR proton energy spectrum in February 2023. We show that Metis plays the role of monitoring galactic and solar protons. The Metis particle observations are used for the diagnostics of the VL instrument performance and to study the spacecraft inner charging from solar minimum towards the next solar maximum. These achievements have been attained with the benefit of the joint observations of Metis, the Energetic Particle Detector/High Energy Telescope, and near-Earth and Earth-based instruments.

Context. Galactic cosmic rays (GCRs) and solar particles with energies greater than tens of MeV penetrate spacecraft and instruments hosted aboard space missions. The Solar Orbiter Metis coronagraph is aimed at observing the solar corona in both visible (VL) and ultraviolet (UV) light. Particle tracks are observed in the Metis images of the corona. An algorithm has been implemented in the Metis processing electronics to detect the VL image pixels crossed by cosmic rays. This algorithm was initially enabled for the VL instrument only, since the process of separating the particle tracks in the UV images has proven to be very challenging. Aims. We study the impact of the overall bulk of particles of galactic and solar origin on the Metis coronagraph images. We discuss the effects of the increasing solar activity after the Solar Orbiter mission launch on the secondary particle production in the spacecraft. Methods. We compared Monte Carlo simulations of GCRs crossing or interacting in the Metis VL CMOS sensor to observations gathered in 2020 and 2022. We also evaluated the impact of solar energetic particle events of different intensities on the Metis images. Results. The study of the role of abundant and rare cosmic rays in firing pixels in the Metis VL images of the corona allows us to estimate the efficiency of the algorithm applied for cosmic-ray track removal from the images and to demonstrate that the instrument performance had remained unchanged during the first two years of the Solar Orbiter operations. The outcome of this work can be used to estimate the Solar Orbiter instrument’s deep charging and the order of magnitude for energetic particles crossing the images of Metis and other instruments such as STIX and EUI.

Context. The Metis coronagraph is one of the remote sensing instruments hosted on board the ESA/NASA Solar Orbiter mission. Metis is devoted to carry out the first simultaneous imaging of the solar corona in both visible light (VL) and ultraviolet (UV). High-energy particles can penetrate spacecraft materials and may limit the performance of the on-board instruments. A study of the galactic cosmic-ray (GCR) tracks observed in the first VL images gathered by Metis during the commissioning phase is presented here. A similar analysis is planned for the UV channel. Aims. We aim to formulate a prediction of the GCR flux up to hundreds of GeV for the first part of the Solar Orbiter mission to study the performance of the Metis coronagraph. Methods. The GCR model predictions are compared to observations gathered on board Solar Orbiter by the High-Energy Telescope in the range between 10 MeV and 100 MeV in the summer of 2020 as well as with the previous measurements. Estimated cosmic-ray fluxes above 70 MeV n−1 have been also parameterized and used for Monte Carlo simulations aimed at reproducing the cosmic-ray track observations in the Metis coronagraph VL images. The same parameterizations can also be used to study the performance of other detectors. Results. By comparing observations of cosmic-ray tracks in the Metis VL images with FLUKA Monte Carlo simulations of cosmic-ray interactions in the VL detector, we find that cosmic rays fire only a fraction, on the order of 10−4, of the whole image pixel sample. We also find that the overall efficiency for cosmic-ray identification in the Metis VL images is approximately equal to the contribution of Z ≥ 2 GCR particles. A similar study will be carried out during the whole of the Solar Orbiter’s mission duration for the purposes of instrument diagnostics and to verify whether the Metis data and Monte Carlo simulations would allow for a long-term monitoring of the GCR proton flux.
